GM Performance 4L75E Transmission
SuperMatic™ 4L75-E Four-Speed Transmission
Similar in design to the 4L65E/4L70-E, this 4L75-E electronically controlled four speed overdrive transmission is suitable for "LS" series V8 engines producing up to 650 Ft. Lbs of torque
• Increased horsepower and torque capacity
• Heavy duty upgrades including 5 pinion gearsets
• Heat treated stator shaft splines
• Induction hardened turbine shaft
• Eight-plate 3-4 clutch packs
• Unique, high-strength input housing
• Specific valve body calibration
• Higher-capacity servo
• Larger 2-4 band
• Gear ratios: 1st-3.06, 2nd-1.62, 3rd-1.00, 4th .070
Does Not include torque converter
To use this transmission with a Gen V LT engine this will require 19125817 bell housing kit
Use with electronic controller 19332775 for carbureted and Ram Jet applications.
Use with electronic controller 19302405 with Chevrolet Performance LS fuel injected applications
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
SuperMatic™ 4L75-E Four-Speed Transmission
Similar in design to the 4L65E/4L70-E, this 4L75-E electronically controlled four speed overdrive transmission is suitable for "LS" series V8 engines producing up to 650 Ft. Lbs of torque
• Increased horsepower and torque capacity
• Heavy duty upgrades including 5 pinion gearsets
• Heat treated stator shaft splines
• Induction hardened turbine shaft
• Eight-plate 3-4 clutch packs
• Unique, high-strength input housing
• Specific valve body calibration
• Higher-capacity servo
• Larger 2-4 band
• Gear ratios: 1st-3.06, 2nd-1.62, 3rd-1.00, 4th .070
Does Not include torque converter
To use this transmission with a Gen V LT engine this will require 19125817 bell housing kit
Use with electronic controller 19332775 for carbureted and Ram Jet applications.
Use with electronic controller 19302405 with Chevrolet Performance LS fuel injected applications
